Soumitra Banerjee

Place:

 Khuman
Maheikol School, Imphal-West, Manipur



 Audience:

 High school students



 Samples
studied:


<ol>
 <li>
 Microstructure
leaf structure
 </li>
 <li>
 Flower
petals microstructure
 </li>
</ol>
<ul class="wp-block-gallery columns-2 is-cropped" data-carousel-extra='{"blog_id":1,"permalink":"https:\/\/microcosmos.foldscope.com\/?p=118286"}'>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="IMG_20181207_142425" class="wp-image-118287 gcloudimg" data-attachment-id="118287" data-comments-opened="1" data-id="118287" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1544192666","copyright":"","focal_length":"3.68","iso":"304","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181207_142425" data-link="https://microcosmos.foldscope.com/?attachment_id=118287" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_118286/IMG_20181207_142425.jpg"/>
 </figure>
 </li>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="IMG_20181207_143221" class="wp-image-118288 gcloudimg" data-attachment-id="118288" data-comments-opened="1" data-id="118288" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1544193141","copyright":"","focal_length":"3.68","iso":"174","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181207_143221" data-link="https://microcosmos.foldscope.com/?attachment_id=118288" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_118286/IMG_20181207_143221.jpg"/>
 </figure>
 </li>
</ul>

North-East Twinning Program: Hands-on-Demonstration of Foldscope and Its Practical Application in Education-#Indiafoldscopephase 1

Place:

 Department of
Microbiology, Government Science college, Bengaluru, Karnataka



 Audience:

 Post graduate students (Microbiology)
(25 students) and Faculty (9 faculties).



 Date:

 04.02.2019



 Samples studied:



 1. Amoeba


 2. Pond water sample


 4. Diseased leaf samples, spores of
fungus


 5. Bacteria and fungus

<ul class="wp-block-gallery columns-3 is-cropped" data-carousel-extra='{"blog_id":1,"permalink":"https:\/\/microcosmos.foldscope.com\/?p=125802"}'>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="DSC_0212" class="wp-image-125807 gcloudimg" data-attachment-id="125807" data-comments-opened="1" data-id="125807" data-image-meta='{"aperture":"2","credit":"","camera":"G3416","caption":"","created_timestamp":"1549283373","copyright":"","focal_length":"4.22","iso":"250","shutter_speed":"0.030006","title":"","orientation":"1"}' data-image-title="DSC_0212" data-link="https://microcosmos.foldscope.com/?attachment_id=125807" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_125802/DSC_0212.jpg"/>
 </figure>
 </li>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="DSC_0216" class="wp-image-125811 gcloudimg" data-attachment-id="125811" data-comments-opened="1" data-id="125811" data-image-meta='{"aperture":"2","credit":"","camera":"G3416","caption":"","created_timestamp":"1549283451","copyright":"","focal_length":"4.22","iso":"500","shutter_speed":"0.030006","title":"","orientation":"1"}' data-image-title="DSC_0216" data-link="https://microcosmos.foldscope.com/?attachment_id=125811" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_125802/DSC_0216-2.jpg"/>
 </figure>
 </li>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="DSC_0225" class="wp-image-125818 gcloudimg" data-attachment-id="125818" data-comments-opened="1" data-id="125818" data-image-meta='{"aperture":"2","credit":"","camera":"G3416","caption":"","created_timestamp":"1549284161","copyright":"","focal_length":"4.22","iso":"200","shutter_speed":"0.030006","title":"","orientation":"1"}' data-image-title="DSC_0225" data-link="https://microcosmos.foldscope.com/?attachment_id=125818" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_125802/DSC_0225-1.jpg"/>
 </figure>
 </li>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="DSC_0218" class="wp-image-125820 gcloudimg" data-attachment-id="125820" data-comments-opened="1" data-id="125820" data-image-meta='{"aperture":"2","credit":"","camera":"G3416","caption":"","created_timestamp":"1549283492","copyright":"","focal_length":"4.22","iso":"200","shutter_speed":"0.030006","title":"","orientation":"1"}' data-image-title="DSC_0218" data-link="https://microcosmos.foldscope.com/?attachment_id=125820" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_125802/DSC_0218-4.jpg"/>
 </figure>
 </li>
</ul>
<ul class="wp-block-gallery columns-3 is-cropped" data-carousel-extra='{"blog_id":1,"permalink":"https:\/\/microcosmos.foldscope.com\/?p=125802"}'>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="DSC_0194" class="wp-image-125803 gcloudimg" data-attachment-id="125803" data-comments-opened="1" data-id="125803" data-image-meta='{"aperture":"2","credit":"","camera":"G3416","caption":"","created_timestamp":"1549279198","copyright":"","focal_length":"4.22","iso":"200","shutter_speed":"0.030006","title":"","orientation":"1"}' data-image-title="DSC_0194" data-link="https://microcosmos.foldscope.com/?attachment_id=125803" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_125802/DSC_0194.jpg"/>
 </figure>
 </li>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="WhatsApp Image 2019-02-11 at 4.11.04 PM" class="wp-image-125804 gcloudimg" data-attachment-id="125804" data-comments-opened="1" data-id="125804" data-image-meta='{"aperture":"0","credit":"","camera":"","caption":"","created_timestamp":"0","copyright":"","focal_length":"0","iso":"0","shutter_speed":"0","title":"","orientation":"0"}' data-image-title="WhatsApp Image 2019-02-11 at 4.11.04 PM" data-link="https://microcosmos.foldscope.com/?attachment_id=125804" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_125802/WhatsApp-Image-2019-02-11-at-4.11.04-PM.jpeg"/>
 </figure>
 </li>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="WhatsApp Image 2019-02-11 at 4.11.06 PM" class="wp-image-125805 gcloudimg" data-attachment-id="125805" data-comments-opened="1" data-id="125805" data-image-meta='{"aperture":"0","credit":"","camera":"","caption":"","created_timestamp":"0","copyright":"","focal_length":"0","iso":"0","shutter_speed":"0","title":"","orientation":"0"}' data-image-title="WhatsApp Image 2019-02-11 at 4.11.06 PM" data-link="https://microcosmos.foldscope.com/?attachment_id=125805" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_125802/WhatsApp-Image-2019-02-11-at-4.11.06-PM.jpeg"/>
 </figure>
 </li>
 <li class="blocks-gallery-item">
 <figure>
 <img alt="WhatsApp Image 2019-02-11 at 4.11.07 PM (1)" class="wp-image-125806 gcloudimg" data-attachment-id="125806" data-comments-opened="1" data-id="125806" data-image-meta='{"aperture":"0","credit":"","camera":"","caption":"","created_timestamp":"0","copyright":"","focal_length":"0","iso":"0","shutter_speed":"0","title":"","orientation":"0"}' data-image-title="WhatsApp Image 2019-02-11 at 4.11.07 PM (1)" data-link="https://microcosmos.foldscope.com/?attachment_id=125806" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_125802/WhatsApp-Image-2019-02-11-at-4.11.07-PM-1.jpeg"/>
 </figure>
 </li>
</ul>

Hands-on Training Workshop on Foldscope and Its Applications- #Indiafoldscopephase 1

We found green colour mold infestation in stored tamarind seeds. Small amount of scrap was taken using forceps and slide was prepared. Mycelial hyphae and spores pictures were taken using foldscope.


 <img alt="IMG_20180727_142918" class="alignnone wp-image-55050 gcloudimg" data-attachment-id="55050" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1532701759","copyright":"","focal_length":"3.68","iso":"1206","shutter_speed":"0.050005","title":"","orientation":"1"}' data-image-title="IMG_20180727_142918" data-recalc-dims="1" height="365" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_55045/IMG_20180727_142918.jpg" width="205"/>
 <img alt="IMG_20180727_143136" class="alignnone wp-image-55051 gcloudimg" data-attachment-id="55051" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1532701897","copyright":"","focal_length":"3.68","iso":"834","shutter_speed":"0.050005","title":"","orientation":"1"}' data-image-title="IMG_20180727_143136" data-recalc-dims="1" height="365" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_55045/IMG_20180727_143136.jpg" width="204"/>
 <img alt="IMG_20180727_142845" class="alignnone wp-image-55052 gcloudimg" data-attachment-id="55052" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1532701726","copyright":"","focal_length":"3.68","iso":"982","shutter_speed":"0.050005","title":"","orientation":"1"}' data-image-title="IMG_20180727_142845" data-recalc-dims="1" height="365" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_55045/IMG_20180727_142845.jpg" width="205"/>


 <img alt="IMG_20180727_141534" class="alignnone wp-image-55053 gcloudimg" data-attachment-id="55053" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1532700934","copyright":"","focal_length":"3.68","iso":"152","shutter_speed":"0.009999","title":"","orientation":"1"}' data-image-title="IMG_20180727_141534" data-recalc-dims="1" height="250" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_55045/IMG_20180727_141534.jpg" width="444"/>
 <img alt="IMG_20180727_161313" class="alignnone wp-image-55054 gcloudimg" data-attachment-id="55054" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1532707993","copyright":"","focal_length":"3.68","iso":"153","shutter_speed":"0.019998","title":"","orientation":"1"}' data-image-title="IMG_20180727_161313" data-recalc-dims="1" height="250" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_55045/IMG_20180727_161313.jpg" width="444"/>


 Fig: Mycelium, fruiting body, spores of green mold


 <a href="https://thewinnower.com/papers/9305-green-mold-under-foldscope-indiafoldscopephase-1" target="_blank">
 This post is open to read and review on The Winnower.
 </a>

Green mold under foldscope-#Indiafoldscopephase 1

In garden of Jyothy Institute of Technology, Bangalore, almost all mango trees got infected with a disease called black band disease.


 <img alt="IMG_20181010_134339" class="alignnone wp-image-71545 gcloudimg" data-attachment-id="71545" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1539179019","copyright":"","focal_length":"3.5","iso":"88","shutter_speed":"0.00683","title":"","orientation":"1"}' data-image-title="IMG_20181010_134339" data-recalc-dims="1" height="323" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_71543/IMG_20181010_134339.jpg" width="182"/>
 <img alt="IMG_20181010_134409" class="alignnone wp-image-71546 gcloudimg" data-attachment-id="71546" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1539179049","copyright":"","focal_length":"3.5","iso":"88","shutter_speed":"0.004436","title":"","orientation":"1"}' data-image-title="IMG_20181010_134409" data-recalc-dims="1" height="260" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_71543/IMG_20181010_134409.jpg" style="font-size: 1.8rem" width="462"/>


 <img alt="IMG_20180904_150343" class="alignnone size-medium wp-image-71547 gcloudimg" data-attachment-id="71547" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1536073423","copyright":"","focal_length":"3.5","iso":"421","shutter_speed":"0.049998","title":"","orientation":"1"}' data-image-title="IMG_20180904_150343" data-recalc-dims="1" height="270" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_71543/IMG_20180904_150343.jpg" style="font-size: 1.8rem" width="300"/>


 Fig: Mango trees in field affected with black band disease and samples collected to observe under foldscope.


 When infected parts  were observed under foldscope we found spherical shaped black lined spores and mycelium aggregations.


 <img alt="IMG_20180904_160604" class="alignnone size-medium wp-image-71548 gcloudimg" data-attachment-id="71548" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1536077164","copyright":"","focal_length":"3.5","iso":"88","shutter_speed":"0.009699","title":"","orientation":"1"}' data-image-title="IMG_20180904_160604" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_71543/IMG_20180904_160604.jpg" width="253"/>
 <img alt="IMG_20180905_140115" class="alignnone size-medium wp-image-71549 gcloudimg" data-attachment-id="71549" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1536156075","copyright":"","focal_length":"3.5","iso":"98","shutter_speed":"0.024993","title":"","orientation":"1"}' data-image-title="IMG_20180905_140115" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_71543/IMG_20180905_140115.jpg" width="235"/>
 <img alt="IMG_20180905_140232" class="alignnone size-medium wp-image-71544 gcloudimg" data-attachment-id="71544" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1536156153","copyright":"","focal_length":"3.5","iso":"114","shutter_speed":"0.016671","title":"","orientation":"1"}' data-image-title="IMG_20180905_140232" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_71543/IMG_20180905_140232.jpg" width="293"/>


 Fig: Spores and Mycelia of infected pathogen under foldscope


 Fungal pathogen

 Peziotrichum corticolum

 causes black band disease of mango and is becoming severe for the last three to four years in all the mango growing regions.

 The pathogen grows superficially on the bark of trees forming large, dark black, irregular, girdle-like infection patches.


 Peziotrichum


 produces septate brown mycelium composed of numerous scattered, erect, vertical aggregations of hyphae closely clustered together and the conidia were single-celled, pale brown, globose, smooth-walled.



 <a href="https://thewinnower.com/papers/9506-black-band-disease-of-mango-indiafoldscopephase-1" target="_blank">
 This post is open to read and review on The Winnower.
 </a>

Black Band disease of Mango-#Indiafoldscopephase 1

Place:

 Rayburn College, New Lamka, Churachandpur, Imphal, Manipur





 Audience:

 Students (More than 100) and Faculties



 Date:

 26.09.2018





 Samples studied:


<ol>
 <li>
 Leaf and flowers
 </li>
 <li>
 Apple sliced
 </li>
 <li>
 Sugar and salt crystal
 </li>
</ol>

 <img alt="IMG_20180926_144622" class="alignnone size-medium wp-image-80218 gcloudimg" data-attachment-id="80218" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1537973182","copyright":"","focal_length":"3.68","iso":"348","shutter_speed":"0.033337","title":"","orientation":"1"}' data-image-title="IMG_20180926_144622" data-recalc-dims="1" height="169" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_80213/IMG_20180926_144622.jpg" width="300"/>
 <img alt="IMG_20180926_144906" class="alignnone size-medium wp-image-80214 gcloudimg" data-attachment-id="80214" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1537973346","copyright":"","focal_length":"3.68","iso":"144","shutter_speed":"0.033337","title":"","orientation":"1"}' data-image-title="IMG_20180926_144906" data-recalc-dims="1" height="169" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_80213/IMG_20180926_144906.jpg" style="font-size: 1.8rem" width="300"/>
 <img alt="IMG_20180926_144903" class="alignnone size-medium wp-image-80282 gcloudimg" data-attachment-id="80282" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1537973343","copyright":"","focal_length":"3.68","iso":"309","shutter_speed":"0.033337","title":"","orientation":"1"}' data-image-title="IMG_20180926_144903" data-recalc-dims="1" height="169" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_80213/IMG_20180926_144903.jpg" width="300"/>
 <img alt="IMG_20180926_151603" class="alignnone size-medium wp-image-80215 gcloudimg" data-attachment-id="80215" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1537974964","copyright":"","focal_length":"3.68","iso":"447","shutter_speed":"0.033337","title":"","orientation":"1"}' data-image-title="IMG_20180926_151603" data-recalc-dims="1" height="169" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_80213/IMG_20180926_151603.jpg" width="300"/>
 <img alt="IMG_20180926_143710" class="alignnone size-medium wp-image-80283 gcloudimg" data-attachment-id="80283" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1537972630","copyright":"","focal_length":"3.68","iso":"294","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20180926_143710" data-recalc-dims="1" height="169" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_80213/IMG_20180926_143710.jpg" width="300"/>
 <img alt="IMG_20180926_160334" class="alignnone wp-image-80216 gcloudimg" data-attachment-id="80216" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1537977814","copyright":"","focal_length":"3.68","iso":"325","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20180926_160334" data-recalc-dims="1" height="219" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_80213/IMG_20180926_160334.jpg" width="289"/>




 <a href="https://thewinnower.com/papers/9624-north-east-twinning-program-workshop-on-foldscope-and-its-applications-for-scientific-education-indiafoldscopephase-1" target="_blank">
 This post is open to read and review on The Winnower.
 </a>

North-East Twinning Program: Workshop on Foldscope and Its Applications for Scientific Education- #Indiafoldscopephase 1

Infestaion found in

 : Black cumin


 <img alt="black cumin" class="size-medium wp-image-86307 aligncenter gcloudimg" data-attachment-id="86307" data-comments-opened="1" data-image-meta='{"aperture":"0","credit":"","camera":"","caption":"","created_timestamp":"0","copyright":"","focal_length":"0","iso":"0","shutter_speed":"0","title":"","orientation":"0"}' data-image-title="black cumin" data-recalc-dims="1" height="297" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/black-cumin.jpg" width="300"/>


 Fig. Infested black cumin spice



 Macrostructure image of infested pest:



 <img alt="Snapshot" class="size-medium wp-image-86305 aligncenter gcloudimg" data-attachment-id="86305" data-comments-opened="1" data-image-meta='{"aperture":"0","credit":"","camera":"","caption":"","created_timestamp":"0","copyright":"","focal_length":"0","iso":"0","shutter_speed":"0","title":"","orientation":"0"}' data-image-title="Snapshot" data-recalc-dims="1" height="169" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/Snapshot.png" width="300"/>


 Fig: Infested pest found in black cumin spice



 Assumed pest:

 Red flour beetle (

 Tribolium castaneum

 )



 Morphological characteristics (as observed under Foldscope)


<ul>
 <li>
 Three-segmented antennal club and last three antennal segments larger than all others, almost square (Fig. 1)
 </li>
 <li>
 Elytra with punctate, parallel-sided striations (Fig. 2)
 </li>
 <li>
 4 segments in tarsus of  hind leg (Fig. 3)
 </li>
 <li>
 Hind wing with folding lines and has dot like cells between the lines
 </li>
</ul>


 <img alt="IMG_20181119_110945" class="alignnone size-medium wp-image-86295 gcloudimg" data-attachment-id="86295" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1542625786","copyright":"","focal_length":"3.5","iso":"315","shutter_speed":"0.040001","title":"","orientation":"1"}' data-image-title="IMG_20181119_110945" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20181119_110945.jpg" width="135"/>

 <img alt="IMG_20181119_111447" class="alignnone size-medium wp-image-86311 gcloudimg" data-attachment-id="86311" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1542626088","copyright":"","focal_length":"3.5","iso":"421","shutter_speed":"0.049998","title":"","orientation":"1"}' data-image-title="IMG_20181119_111447" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20181119_111447.jpg" style="font-size: 1.8rem" width="168"/>




 Fig(1): Antennae of Red flour beetle under foldscope


 <img alt="IMG_20181120_163711" class="alignnone wp-image-86296 gcloudimg" data-attachment-id="86296" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542731832","copyright":"","focal_length":"3.68","iso":"248","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181120_163711" data-recalc-dims="1" height="236" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20181120_163711.jpg" width="239"/>
 <img alt="IMG_20181120_163622" class="alignnone wp-image-86297 gcloudimg" data-attachment-id="86297" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542731782","copyright":"","focal_length":"3.68","iso":"300","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181120_163622" data-recalc-dims="1" height="222" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20181120_163622.jpg" width="192"/>


 Fig(2): Elytra of Red flour beetle under foldscope


 <img alt="IMG_20180726_120341" class="alignnone size-medium wp-image-86298 gcloudimg" data-attachment-id="86298" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1532606621","copyright":"","focal_length":"3.68","iso":"118","shutter_speed":"0.009999","title":"","orientation":"1"}' data-image-title="IMG_20180726_120341" data-recalc-dims="1" height="161" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20180726_120341.jpg" width="300"/>
 <img alt="IMG_20181120_165247" class="alignnone wp-image-86299 gcloudimg" data-attachment-id="86299" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542732767","copyright":"","focal_length":"3.68","iso":"186","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181120_165247" data-recalc-dims="1" height="182" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20181120_165247.jpg" width="212"/>
 <img alt="IMG_20181120_164308" class="alignnone wp-image-86301 gcloudimg" data-attachment-id="86301" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542732188","copyright":"","focal_length":"3.68","iso":"163","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181120_164308" data-recalc-dims="1" height="202" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20181120_164308.jpg" width="73"/>
 <img alt="IMG_20181120_164154" class="alignnone wp-image-86302 gcloudimg" data-attachment-id="86302" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542732114","copyright":"","focal_length":"3.68","iso":"174","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181120_164154" data-recalc-dims="1" height="196" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20181120_164154.jpg" width="75"/>


 Fig(3 ):  Hind leg of Red flour beetle under foldscope


 <img alt="IMG_20180726_111929" class="alignnone size-medium wp-image-86304 gcloudimg" data-attachment-id="86304" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1532603969","copyright":"","focal_length":"3.68","iso":"127","shutter_speed":"0.009999","title":"","orientation":"1"}' data-image-title="IMG_20180726_111929" data-recalc-dims="1" height="169" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20180726_111929.jpg" width="300"/>
 <img alt="IMG_20180726_112316" class="alignnone size-medium wp-image-86303 gcloudimg" data-attachment-id="86303" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1532604196","copyright":"","focal_length":"3.68","iso":"165","shutter_speed":"0.009999","title":"","orientation":"1"}' data-image-title="IMG_20180726_112316" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86294/IMG_20180726_112316.jpg" width="169"/>


 Fig(1): Hind wing of Red flour beetle under foldscope


 <a href="https://thewinnower.com/papers/9688-identification-keys-of-storage-pest-red-flour-beetle-indiafoldscopephase-1" target="_blank">
 This post is open to read and review on The Winnower.
 </a>

Identification keys of storage pest: Red flour beetle- #Indiafoldscopephase 1

Bean aphid




 Scientific name

 : Aphis craccivora





 Aphis craccivora

 prefers plants in the Fabaceae (beans, peas and groundnuts), but it is highly
 <a alt="Aphid-glossary.htm#polyphagous" class="d gcloudimg" href="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86962/Aphid-glossary.htm%23polyphagous" title="polyphagous: Able to feed on a wide range of host plant species. ">
 polyphagous
 </a>
 and has been found on many plant species. It feeds on the young shoots, leaves, flowers and fruits, and is strongly ant attended.  It is also a vector of several viruses including broad bean mosaic virus, cucumber mosaic virus and groundnut rosette virus. The cowpea aphid has a cosmopolitan distribution.


 <img alt="IMG_20180825_134419" class="size-medium wp-image-86972 aligncenter gcloudimg" data-attachment-id="86972" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"XT1706","caption":"","created_timestamp":"1535204659","copyright":"","focal_length":"3.5","iso":"313","shutter_speed":"0.033328","title":"","orientation":"1"}' data-image-title="IMG_20180825_134419" data-recalc-dims="1" height="168" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86962/IMG_20180825_134419.jpg" width="300"/>


 Fig. 1: Aphids feeding on plant leaf


 <img alt="IMG_20180825_135330" class="alignnone wp-image-86968 gcloudimg" data-attachment-id="86968" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1535205210","copyright":"","focal_length":"3.68","iso":"114","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20180825_135330" data-recalc-dims="1" height="249" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86962/IMG_20180825_135330.jpg" style="font-size: 1.8rem" width="442"/>
 <img alt="IMG_20181117_104321" class="alignnone size-medium wp-image-86975 gcloudimg" data-attachment-id="86975" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542451401","copyright":"","focal_length":"3.68","iso":"229","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181117_104321" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86962/IMG_20181117_104321.jpg" width="229"/>


 Fig. 2: Dorsal view of Bean aphid observed under foldscope


 <img alt="IMG_20181117_095756" class="alignnone size-medium wp-image-86974 gcloudimg" data-attachment-id="86974" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542448676","copyright":"","focal_length":"3.68","iso":"187","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181117_095756" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86962/IMG_20181117_095756.jpg" width="169"/>
 <img alt="IMG_20181117_103742" class="alignnone size-medium wp-image-86991 gcloudimg" data-attachment-id="86991" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542451062","copyright":"","focal_length":"3.68","iso":"158","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181117_103742" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86962/IMG_20181117_103742.jpg" width="169"/>
 <img alt="IMG_20181117_103823" class="alignnone size-medium wp-image-86994 gcloudimg" data-attachment-id="86994" data-comments-opened="1" data-image-meta='{"aperture":"2.2","credit":"","camera":"Lenovo A7020a48","caption":"","created_timestamp":"1542451103","copyright":"","focal_length":"3.68","iso":"154","shutter_speed":"0.039995","title":"","orientation":"1"}' data-image-title="IMG_20181117_103823" data-recalc-dims="1" height="300" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_86962/IMG_20181117_103823.jpg" width="236"/>


 Fig. 3: Leg of Bean aphid observed under foldscope


 <a href="https://thewinnower.com/papers/9699-north-east-twinning-program-bean-aphid-from-north-east-under-foldscope-indiafoldscopephase1" target="_blank">
 This post is open to read and review on The Winnower.
 </a>
