 Methodology:
</p>
<ul>
 <li>
  Root tips 1 to 2 cm was cut and incubated in Carnoy’s fixative for 15 to 20 minutes.
 </li>
 <li>
  Then washed thoroughly in water 2 to 3 times.
 </li>
 <li>
  The root tips was transfered in 1N Hydrochloric acid and incubate at 60°C for 5 minutes.
 </li>
 <li>
  Stained with acetocarmine for 10 minutes. Transferred onto a clean slide and covered with a cover slip.
 </li>
 <li>
  Gently tap the root and observe under the Microscope and Foldscope
 </li>
</ul>
<p>
 Stage Acronyms
</p>
<p style="text-align:center">
 Interphase: S
</p>
<p style="text-align:center">
 Prophase: 1
</p>
<p style="text-align:center">
 Metaphase: 2
</p>
<p style="text-align:center">
 Anaphase: 3
</p>
<p style="text-align:center">
 Telophase: 4
</p>
<div class="wp-block-image">
 <figure class="aligncenter is-resized">
  <img alt="1545115379596_Microscope blood stain" class="wp-image-107879 gcloudimg" data-attachment-id="107879" data-comments-opened="1" data-image-meta='{"aperture":"0","credit":"","camera":"","caption":"","created_timestamp":"0","copyright":"","focal_length":"0","iso":"0","shutter_speed":"0","title":"","orientation":"1"}' data-image-title="1545115379596_Microscope blood stain" data-recalc-dims="1" height="534" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_107878/1545115379596_Microscope-blood-stain.jpg" width="498"/>
  <figcaption>
   Mitosis stages as seen under Microscope
  </figcaption>
 </figure>
</div>
<div class="wp-block-image">
 <figure class="aligncenter">
  <img alt="Foldscope blood stain" class="wp-image-107881 gcloudimg" data-attachment-id="107881" data-comments-opened="1" data-image-meta='{"aperture":"1.7","credit":"","camera":"ONEPLUS A6000","caption":"","created_timestamp":"1545061160","copyright":"","focal_length":"4.25","iso":"500","shutter_speed":"0.03030303030303","title":"","orientation":"1"}' data-image-title="Foldscope blood stain" src="https://storage.googleapis.com/microcosmosdelta.appspot.com/images/transfer_107878/Foldscope-blood-stain-1.jpg"/>
  <figcaption>
   <br/>
   Mitosis stages as seen under Foldscope
  </figcaption>
 </figure>
</div>


Observation of Mitosis Stages In Onion Root tip
