Foldscope and Raspberry Pi computer – Digital Microscope.

Dec 11, 2018 • 2:55 AM UTC

Unknown Location

140x Magnification

Microorganisms

Iype

I am a Medical Doctor in Kerala Health Services Department. Now, I am on deputation to Rajiv Gandhi Centre for Biotechnology (RGCB) (GOI - DBT), Trivandrum, Kerala as Research Scientist (Epidemiology). My personal interest is in Leptospirosis and Typhus. I also work closely with other scientists who study Influenza, Measles, Diarrhoea, Cholera, Dengue, Chikungunya, Malaria and Non-communicable diseases.

4posts

0comments

0locations

Foldscope and Raspberry Pi computer. Ticks collected from Rodents are mounted on glass slides. It is kept on the Foldscope. Manual focusing is done. Then the camera attached to the Raspberry Pi is placed in the same way as the camera of the Mobile. The image is captured in the Raspberry Pi computer. It can be seen on the Monitor too. Note the light source used (kept in the background)

Raspberry Pi computer seen from behind the monitor. The “Computer” is the small electronic board attached to the back side. See the camera module too.

Picture of the Tick seen on the Raspberry Pi monitor.

Tick image recorded by the Raspberry Pi computer
